Model No: LTSA599
LTSA599 ISO18752-DC SUPER ARTERY® WIRE SPIRAL HYDRAULIC HOSE
Application： Remarkable performance on tight bend radius, high pressure, longservice life, and high impulse, weather resistant for more than five years and warrantied for two years with Letone hose fittings and HNBR seals. Widely apply to excavator and other heavy duty construction machinery or hash working environment.
Inner Tube：CR/NBR synthetic rubber
Reinforcement：multi-spiraled high tensile super flexible steel wire,four plies ≥ 1 million impulse cycles
Outer Layer：skiving-free abrasion and weather resistant synthetic rubber
Temperature Range：-40°C 〜+121°C (-40°卜+250°F) ;-55°C 〜+100°C (-67°F- +212°F)
Standard：Comply with ISO18752-DC standard
Features： Low bending radius; high pressure ; long service life ( weather resistant for more than 5 years and warrantied for 2 years with Letone specific hose connectors)
Inner Tube：CR/NBR synthetic rubber
Reinforcement：multi-spiraled high tensile super flexible steel wire,four plies ≥ 1 million impulse cycles
Outer Layer：skiving-free abrasion and weather resistant synthetic rubber
Temperature Range：-40°C 〜+121°C (-40°卜+250°F) ;-55°C 〜+100°C (-67°F- +212°F)
Standard：Comply with ISO18752-DC standard
Features： Low bending radius; high pressure ; long service life ( weather resistant for more than 5 years and warrantied for 2 years with Letone specific hose connectors)
Quantity :
This high-performance flexible hydraulic hose is engineered for demanding applications like excavators. Its remarkable tight bend radius and durability make it ideal for harsh conditions. Constructed with a synthetic rubber tube and multi-spiraled steel wire reinforcement, this braided hydraulic hose exceeds 1 million impulse cycles. The abrasion-resistant cover provides weather protection for over five years. Unlike thermoplastic hydraulic hose options, this flexible hydraulic hose offers superior impulse resistance and flexibility. Operating from -40°C to +121°C, it ensures reliable performance in dynamic systems. This braided hydraulic hose outperforms thermoplastic hydraulic hose in extreme environments. With exceptional flexibility, this flexible hydraulic hose routes easily in tight spaces. Supported by a two-year warranty, this braided hydraulic hose complies with ISO18752. Combining the best of braided hydraulic hose and thermoplastic hydraulic hose technologies, this flexible hydraulic hose delivers unmatched versatility and strength.
