Model No: LT699
LT699 1S018752-AC/BC ARTERY WIRE BRAID HYDRAULIC HOSE
Applications： Remarkable performance on high pressure and high impulse. Widely apply to excavator and other heavy duty construction machinery.
Inner Tube:NBR synthetic rubber：
Reinforcement:one or two braids of high tensile super flexible steel wire,one braid >300,000 impulse cycles,two braids >500,000impulse cycles：
Outer Layer:skiving-free oil, abrasion, and weather resistant synthetic rubber.：
Temperature Range:-40C~+100C(-40F-+212F)-55C +100C(67+212F）.：
Inner Tube:NBR synthetic rubber：
Reinforcement:one or two braids of high tensile super flexible steel wire,one braid >300,000 impulse cycles,two braids >500,000impulse cycles：
Outer Layer:skiving-free oil, abrasion, and weather resistant synthetic rubber.：
Temperature Range:-40C~+100C(-40F-+212F)-55C +100C(67+212F）.：
Quantity :
This heavy-duty hydraulic hose excels in high-pressure and high-impulse applications, ideal for excavators and construction machinery. It features a durable NBR synthetic rubber tube, compatible with various hydraulic fluids. Reinforced with high-tensile steel wire braids, it exceeds 300,000 impulse cycles (single-braid) and 500,000 (double-braid). The skiving-free synthetic rubber cover resists oil, abrasion, and weather. Operating from -40°C to +100°C, it ensures reliability. Compatible with reusable hydraulic hose fittings, these hydraulic connectors enable quick field repairs. Using reusable hydraulic hose fittings reduces downtime and inventory. These reusable hydraulic hose fitting systems offer versatile hydraulic connectors. The advantage of reusable hydraulic hose fittings is easy disconnection and reassembly. -hydraulic connectors
